1、 560 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and wireless microphone;
2. Ultra thin wall mounted precision hardware box, the whole machine is an all metal shell, which can better shield peripheral signals, anti-interference
Anti collision, anti-theft and heat dissipation;
3. LCD screen capable of displaying operation status;
4. Built in multifunctional central control;
5. Built in 5 million / 8 million / 12 million / 13 million pixel display platform;
6. Built in sound system, power: 35wx2 (external passive speaker can be connected); Speaker with built-in sound system: 4 inches
Bass x1, 3-inch treble X1;
7. Built in wireless microphone receiving module;
8. The wireless microphone can work independently without turning on the computer;
9. Unique ESD electrostatic protection function, hot plug will not damage internal components;
10. Multiple configurations can be selected for the computer;
11. With built-in Bluetooth function, it can wirelessly connect mobile phones, tablets, laptops, etc. with Bluetooth function
Device for audio transmission.
Model: yt-560c price: 13800 yuan
2、 530 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and wireless microphone;
2. Ultra thin wall mounted precision hardware box. The whole machine is an all metal shell, which can better shield peripheral signals, anti-interference, anti-collision and anti-theft;
3. LCD screen capable of displaying operation status;
4. Built in multifunctional central control;
5. Built in 5 million / 8 million / 12 million / 13 million pixel display platform;
6. Built in sound system, power: 35wx2 (external passive speaker can be connected); Speaker with built-in sound system: 4-inch bass x1, 3
Inch treble X1;
7. Built in wireless microphone receiving module;
8. The wireless microphone can work independently without turning on the computer;
9. Unique ESD electrostatic protection function, hot plug will not damage internal components;
10. Multiple configurations can be selected for the computer;
11. The computer and central control parts adopt the plug-in structure of independent chassis, which is easy to disassemble and easy to maintain.
Model: yt-530a price: 16800 yuan
3、 510 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and wireless microphone;
2. Ultra thin wall mounted precision hardware box. The whole machine is an all metal shell, which can better shield peripheral signals and resist interference,
Anti collision and anti-theft;
3. The control mode is inductive key; LCD display screen capable of displaying operation status;
4. Built in multifunctional central control;
5. Built in 5 million / 8 million / 12 million / 13 million pixel display platform;
6. Built in sound system, power: 35wx2 (external passive speaker can be connected); Speaker with built-in sound system: 4-inch bass x1, 3-inch treble X1;
7. Built in wireless microphone receiving module;
8. The wireless microphone can work independently without turning on the computer;
9. Unique ESD electrostatic protection function, hot plug will not damage internal components;
10. Multiple configurations can be selected for the computer;
11. Optional card swiping system for unified management.
Model: yt-510a price: 17800 yuan
Model: yt-510b price: 18800 yuan
4、 520 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and wireless microphone;
2. Ultra thin wall mounted precision hardware box. The whole machine is an all metal shell, which can better shield peripheral signals and resist interference
, anti-collision and anti-theft;
3. The control mode is inductive key; LCD display screen capable of displaying operation status;
4. Built in multifunctional central control;
5. Built in 5 million / 8 million / 12 million / 13 million pixel display platform;
6. Built in sound system, power: 35wx2 (external passive speaker can be connected); Speaker with built-in sound system: 4-inch bass x1, 3-inch
Treble X1;
7. Built in wireless microphone receiving module;
8. The wireless microphone can work independently without turning on the computer;
9. Unique ESD electrostatic protection function, hot plug will not damage internal components;
10. Multiple configurations can be selected for the computer;
11. The panel is equipped with liquid crystal display;
12. Optional card swiping system for unified management.
Model: yt-520a price: 18800 yuan
Model: yt-520b price: 19800 yuan
5、 500 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and multifunctional microphone;
2.wall mounted on either side of the writing board;
3. The cooling time of projector shutdown can be set through software to better protect the service life of projector;
4. Built in multifunctional central control system; (shutdown key, volume control key, signal switching key)
5. Built in 5 million / 8 million / 12 million / 13 million pixel display platform and 1 / 3-inch COMS lens; SNR ≤ 50dB.
6. Built in sound system, power: 35W × 2 (external passive speaker can be connected); A pair of wooden passive speakers, single box power ≥ 20W, impedance 8 Ω;
7. The multi-functional microphone adopts 2.4G connection, automatic code checking after startup, integrates functions such as wireless microphone, laser pointer, PPT page turning, wireless mouse, etc., and has a built-in high-capacity lithium battery, which can be recharged circularly, which is more environmentally friendly and energy-saving. It can be used continuously for more than 6 hours when fully charged each time.
8. Rich external interfaces can better meet the needs of teachers (3.5 audio input interfaces ≥ 1, 3.5 audio output interfaces ≥ 1, HDMI signal input interfaces ≥ 2, HDMI signal output interfaces ≥ 2, Gigabit network interfaces ≥ 1, power input interfaces ≥ 1, power output interfaces ≥ 1, special control interfaces ≥ 1, USB2.0 ≥ 2, USB3.0 ≥ 1.);
9. The OPS computer module can be configured with a variety of CPU I3 / i5 / i7 (sixth, seventh and eighth generation) memory 4G / 8g (DDR4) mechanical hard disk / solid state hard disk (500g / 1t / 128G / 256g) integrated graphics card / sound card / network card, and equipped with wireless keyboard and mouse;
10. It can swipe card, press button and other startup methods.
The following optional functions:
1. It has wireless routing function and local web management platform;
2. QQ platform management system: after binding the equipment, you can view the equipment operation status on QQ and monitor the terminal equipment in real time.
Model: yt-500a price: 16800 yuan
Model: yt-510b price: 17800 yuan
6、 600 series wall mounted integrated machine
characteristic:
1. Built in computer, central control, display desk, stereo and multifunctional microphone;
2. Wall mounted on either side of the writing board; Modular front disassembly design and door panel damping design;
3. The cooling time of projector shutdown can be set through software to better protect the service life of projector;
4. Built in multifunctional central control system; (shutdown key, volume control key and signal switching key) it can not only switch the machine with one key, but also distinguish and control each power supply;
5. Built in 5 million, 1 / 3-inch COMS lens, 12 times optical zoom and 12 times digital zoom; SNR ≤ 50dB. The lens has a double-layer structure, the image can be rotated more than 180 degrees, and has an independent capacitive touch button and knob to support zoom in and out and other operations;
6. Built in sound system, power: 35W × 2 (external passive speaker can be connected); A pair of wooden passive speakers, single box power ≥ 20W, impedance 8 Ω;
7. The multi-functional microphone adopts 2.4G connection, automatic code alignment after startup, supports screen display, integrates functions such as wireless microphone, laser pointer, PPT page turning and wireless mouse, and has a built-in high-capacity lithium battery, which can be recharged circularly, which is more environmentally friendly and energy-saving. It can be used continuously for more than 6 hours when fully charged each time;
8. Rich external interfaces can better meet the needs of teachers (3.5 audio input interfaces ≥ 3, 3.5 audio output interfaces ≥ 1, VGA input interfaces ≥ 3, VGA output interfaces ≥ 2, HDMI signal input interfaces, 3, HDMI signal output interfaces ≥ 2, Gigabit network interfaces ≥ 4, power input interfaces ≥ 1, power output interfaces ≥ 3, special control interfaces ≥ 1, RS232 ≥ 1, USB2.0 ≥ 8, USB3.0 ≥ 1.);
9. The OPS computer module can be configured with a variety of CPU I3 / i5 / i7 (sixth, seventh and eighth generation) memory 4G / 8g (DDR4) mechanical hard disk / solid state hard disk (500g / 1t / 128G / 256g) integrated graphics card / sound card / network card, and equipped with wireless keyboard and mouse;
10. It can swipe card, press button and other startup methods.
The following optional features:
1. It has wireless routing function and local web management platform;
2. QQ platform management system: after binding the equipment, you can view the equipment operation status on QQ and monitor the terminal equipment in real time.
Model: yt-500c price: 17800 yuan
Model: yt-510d price: 18800 yuan
|
